3000W Planar Thick Film, Non-inductive High-power Resistor

Application Fields

Suitable for variable speed drives, power supplies, control equipment, robotics, motor control, and other electrical designs, the easy-to-install device ensures an automatically calibrated pressure of approximately 300N on the cooling plate.

Features

• Operating Power: 3000W

• Non-inductive Design

• Compliant with ROHS Standards

• High Insulation and Partial Discharge Performance

• Materials compliant with UL 94 V-0 Standards

• Resistors can be provided with pre-co

Continued

Resistance Value: ≥0.1 Ω to ≤6 kΩ
Resistance Tolerance: ±5% to ±10%
Temperature Coefficient: Standard at ±250 ppm/°C
Power Rating: 3000 W at 110°C Case Temperature
Short-time Overload: 3600 W for 10 seconds at 70°C, ΔR = 0.4%
Maximum Operating Voltage: 5000 V DC / 3500 V AC RMS (50 Hz), higher voltages can be customized upon request but must not exceed the rated power
Maximum Continuous Current: 150 A (AC or DC versions)
Dielectric Strength Voltage: 7 kVrms/50 Hz/500 VA, tested between terminals and case for 1 minute (up to 12 kVrms can be tested upon request to prevent long-term damage)
Partial Discharge: 4 kVrms < 10 pC (up to 7 kVrms < 10 pC upon request, compliant with IEC 60270)
Peak Current: Up to 1500 A depending on pulse length and frequency (inquire for specifics)
Insulation Resistance: > 10 GΩ at 1000 V
Single Impulse Voltage: Standard at 12 kV (pulse width 1/50 μs)
Creepage Distance: >42 mm (standard, can be higher upon request)
Clearance: >14 mm (standard, can be higher upon request)
Inductance: ≤80 nH (typical, measured at 10 kHz)
Capacitance/Mass: ≤140 pF (typical, measured at 10 kHz)
Capacitance/Parallel: ≤40 pF (typical, measured at 10 kHz)
Operating Temperature: -55°C to +155°C
Mounting - Torque (Contacts): 1.8 Nm to 2 Nm
Mounting - Torque (M4 Screws): 1.6 Nm to 1.8 Nm
Internal Temperature Sensor (optional): PT-1000 / PT-100 / Type K / Type J (consult for details)
Cable Type (optional): HV-cable / Flying leads (consult for details)
Standard Cable Type: H&S Radox 9 GKW AX 1.5 mm²
Weight: Approximately 120 g

General Specifications

Electrical Support:
Alumina ceramic metallization with Miba resistor ALTOX film on the bottom for better heat transfer and optimal discharge effects.
Encapsulation:
Resin-filled epoxy resin case with large creepage distance, large electrical clearance between terminals, and high insulation resistance (CTI 600).
Resistance Element:
Specially designed for low inductance and capacitance values. The element uses special METOXFILM, demonstrating stability under high power and pulse loads.
Case:
The case has no color additives. The color is natural and may vary due to different pigmentation.
Connections:
Easily connect loads with M4 and M5 screws (British standard threaded terminals available upon request).
Connector height ranges from 25 to 42 mm.
Various bushings can increase the creepage distance to 85 mm or provide potted cable connections (available upon request).
Standard contacts are M5 (M4 connection screws with a maximum thread of 7 mm available upon request).
