30W TO-220 Planar Alloy Foil, Non-inductive Power Resistor

The TO-220 package features a resistor chip made of alloy foil material, which is suitable for low resistance ranges. It boasts a low temperature coefficient and strong pulse tolerance, making it ideal for applications such as current sampling circuits.

● Rated power of 30W at a baseplate center temperature of ≤25°C
● Transient current: I ≤ 200A (single pulse energy ≤ 20J)
● Standard TO-220 mold-encapsulated package with an exposed ceramic substrate
● Baseplate secured by M3 screws
● Standard lead configuration for easy installation; the resistor package is fully insulated from the heatsink.

1. Resistance range: 0.05Ω~0.05Ω (Other resistance values can be negotiated and ordered)

2. Resistance accuracy: ±5%~±10%

3. Rated power: Rated power is 30W at 25°C, maximum operating voltage is 420VDC

4. Dielectric withstand voltage: 1,800VAC

5. Insulation resistance: Minimum 10GΩ

6. Instantaneous overload: Twice the rated power, but not exceeding 1.5 times the maximum continuous operating voltage, for 5 consecutive seconds, ΔR≤±(0.3%R + 0.001Ω)

7. Power durability: Rated power for 2,000 hours, MIL - R - 39009 ΔR≤±(1.0%R + 0.001Ω)

8. Moisture resistance: MIL - Std - 202, method 106, ΔR≤±(0.5%R + 0.001Ω)

9. Thermal shock: MIL - Std - 202, method 107, condition F, ΔR≤±(0.3%R + 0.001Ω)

10. Terminal strength: MIL - Std - 202, method 211, condition A, tensile test 2.4 Newtons, ΔR≤±(0.2%R + 0.001Ω)

11. High - frequency vibration: MIL - Std - 202, method 204, condition D, ΔR≤±(0.2%R + 0.001Ω)

12. Lead material: Anti - oxidation tinned copper wire

13. Maximum torque for M3 screws: 0.9Nm
