Molded Thick Film Divider, High Voltage, High Precision, Surface-Mount

image.pngMetal Film Precision High Voltage MELF Resistor (CSRP Series)500V-1000VCSRP±0.1％
±0.25％
±0.5％
±1％
image.pngMELF High Voltage Resistor (CSRH Series)1500V-2500VCSRH±1%
           ±5%
image.pngESD Surge MELF Absorber1300VESM±30%
image.pngHigh Voltage MELF Resistor600V-8400VHVM±1%
             ±2%
             ±5%
image.pngMedium Voltage MELF Resistor750V-1000VMVM±1%
±2%
±5%

Molded Thick Film Divider, High Voltage, High Precision, Surface-Mount are specialized electronic components that combine several key features to provide robust and reliable performance in various applications. Below is a detailed overview of these components:

Key Features

  1. Molded Thick Film Technology

    • This technology involves depositing a thick film of resistive material onto a substrate, which is then molded into the desired shape.

    • The molded construction provides enhanced mechanical stability and durability, ensuring that the divider can withstand harsh operating environments.

  2. High Voltage Capability

    • These dividers are designed to handle high voltages, typically ranging from several hundred volts to several thousand volts.

    • This makes them suitable for applications in high-voltage circuits, such as those found in power supplies, industrial machinery, and automotive systems.

  3. High Precision

    • The resistors within the divider are manufactured to precise tolerance levels, ensuring accurate voltage division.

    • This high precision is crucial for applications that require precise control of electrical currents and voltages, such as in precision instrumentation and telecommunication systems.

  4. Surface-Mount Design

    • The surface-mount design allows for easy integration of the divider into electronic circuits.

    • It reduces the footprint of the component, enabling more compact and efficient circuit designs.

    • Additionally, surface-mount components are easier to automate in production processes, reducing manufacturing costs and time.

Applications

  • Power Supplies: Used in power supplies to regulate and control voltage levels, ensuring stable and reliable power output.

  • Industrial Machinery: Found in industrial machinery where high-voltage circuits are required for operation, such as in motors, controllers, and sensors.

  • Automotive Systems: Utilized in automotive systems for voltage regulation and control in various subsystems, such as lighting, infotainment, and safety systems.

  • Precision Instrumentation: Suitable for use in precision instrumentation where accurate voltage division is crucial for the accuracy and performance of the equipment.

  • Telecommunication Systems: Employed in telecommunication systems for signal processing and transmission, ensuring stable and reliable communication networks.

Benefits

  • Enhanced Reliability: The molded construction and thick film technology provide enhanced reliability and durability, ensuring long-term performance in harsh environments.

  • Compact Design: The surface-mount design allows for more compact and efficient circuit designs, reducing the overall size and weight of electronic devices.

  • High Precision: The high precision of the resistors within the divider ensures accurate voltage division, providing better control and performance in applications that require precise electrical parameters.

In summary, Molded Thick Film Divider, High Voltage, High Precision, Surface-Mount components offer a combination of key features that make them suitable for a wide range of applications. Their enhanced reliability, compact design, and high precision make them invaluable in various industries and applications.
